Chapter 1: Introduction

1.1 First steps

Checking the delivery

Please check the delivery without delay for damaged or missing parts.
In case of incomplete delivery or defective parts, indicate the respec-
tive items on the freight documents and contact the carrier or your
local PRÜFTECHNIK sales partner.
Standard package (VIB 5.890-3) and measuring equipment*
1: VIBRONET Signalmaster basic unit, VIB 5.802
2: Shock pulse module, VIB 5.815-3
3: System components, mounted in the cabinet:
Shield clamps, Ethernet, relay, terminal block, power supply
4: MUXes*
5: Sensors and cables*
What is not included
Project-specific measuring equipment, such as MUXes, sensors, ca-
bles, installation material is not included with the standard package
VIB 5890-3.
Responsibilities
The owner / operator of the system must ensure that
- all applicable national regulations, all safety, accident prevention
and environmental protection regulations as well as the recog-
nized safety rules and safe work practices are complied with
- all tasks required for the proper installation of the system compo-
nents are performed correctly:
- the system is installed by a qualified specialist.
- all components and tools required for the installation are availa-
ble (see also "Installation").
- electric power and a data network connection that conforms to
the specifications are available.
- a potential equalization connection is available.

1.2 Service addresses

If you have any questions, please contact us:
Telephone: +49 89 99616-0
www.pruftechnik.com
Fluke Deutschland GmbH
Freisinger Str. 34
85737 Ismaning, Germany
Serial number
When calling our hotline, please have the serial number of the re-
spective components at hand.
7
Introduction
1
2
3
4*
5*
