Technical data
Maximum operating pressure
Maximum ambient temperature
Maximum water temperature
Supply voltage
Frequency
Maximum relative humidity
Maximum altitude for installation (standard product )
Protection class of switchgear
Protection class electric motor
Insulation class electric motor
Efficiency class electric motor
(*) Ask Wilo and check the specific graphs and tables in the cat -
alogues and maintenance manuals for the details of class varia -
tions for electric motors and diesel motors regarding different
temperatures, altitudes, atmospheric pressure, fuel tempera -
ture, and viscosity compared to standard test conditions.

5.2 Scope of delivery

• Fire-extinguishing system (pump, drive, coupling,
base frame, switchgear)
• Automatic air vent valve
• Suction and discharge pressure gauges
• Installation and operating instructions for fire
extinguishing system.
• Installation and operating instructions for pumps
• Installation and operating instructions for switch -
gears (one manual per switchgear type)
• Installation and operating instructions and main -
tenance instructions of the drive.
VALVE DETAILS
Sr. Description
No.
1 Air vent valve
2 Circulation relief valve 20-200 PSI
3 Circulation relief valve 20-200 PSI
4 Circulation relief valve 100-300 PSI
5 Pressure relief valve
6 Pressure relief valve
7 Pressure relief valve
8 Pressure relief valve
The installer is responsible for the assembly of the
equipment supplied and for completion of the
system in compliance with the requirements of
NFPA20 and other applicable standards with
regard to fire-extinguishing systems, as well as for
integration of our supply with all other necessary
components (circulation piping, flow rate meter -
ing circuits with meter, etc.).
8
16 bar
5 to +25°C (10 to 25°C if diesel pump is installed)
30°C
3x400V +/- 10% (1x230V +/- 10%, for diesel pump switchgear)
50 Hz
50% with T.max 40°C (*)
Diesel: 91 m - Electric: 300 m
Refer to the rating plate
Refer to the rating plate
Refer to the rating plate
Refer to the rating plate
Pressure rating Size
300 PSI 1/2" (15 mm)
1/2" (15 mm)
3/4" (20 mm)
3/4" (20 mm)
20-200 PSI 3" (75 mm)
20-200 PSI 4" (100 mm)
20-200 PSI 6" (150 mm)
20-200 PSI 8" (150 mm)

5.3 Accessories

• Exhaust kit for diesel engine
• Flow meter
• Eccentric reducer
• Concentric increaser
• Pressure relief valve
• Circulation relief valve.
• Independent fuel tank for the diesel motor with
accessories;
Make Model
CLA VAL CLA-VAL 3450 -AR 116.3
- Air vent valve DI
- FM-approved
CLA VAL CLA-VAL 55L-60
MOC: bronze, body stainless steel Trim
CLA VAL
Pressure range: adjustable range 20-200 PSI
CLA VAL CLA-VAL 55L-60
MOC: bronze, body Stainless Steel Trim
Pressure range: adjustable range 100-300 PSI
CLA VAL Model: 2050B-4KG1
MOC: ductile iron
CLA VAL
Body with SST trim, copper tube, and fittings,
CLA VAL
bronze pilot
CLA VAL
Pressure range 20-200 PSI;
Flange: DN 150 or DN 300
Pattern: angle pattern
red epoxy coated
See the specific instructions provided in the rele -
vant Installation and operating instructions and/or
the indications provided on the items themselves
for details of how to assemble, set, and adjust the
previously listed accessories or other particular
accessories requested at the order stage and sup -
plied with the standard pumping unit.
