Guidance and manufacturer's declaration –
The system is intended for use in the electromagnetic environment specified
below. The customer or the user of the system should assure that it is used in
such an environment.
Immunity Test IEC 60601-1-2
test level
Electrostatic +/- 8 kV contact
discharge (ESD)
+/- 2, 4, 8,
IEC 61000-4-2 15 kV air
Electrical fast +/- 2 kV
transient / burst for mains
supply lines
IEC 61000-4-4
+/- 1 kV for input
/ output lines
Surge +/- 0.5, 1 kV
line(s) to line(s)
IEC 61000-4-5
+/- 0.5, 1, 2 kV
line(s) to earth
Voltage Dips, 0% Ut
short interruptions (100% dip in Ut)
and voltage for 0.5 cycle at
variations on 8 angels
power supply
0% Ut
input lines
(100% dip in Ut)
IEC 61000-4-11
for 1 cycle
70% Ut
(30% dip in Ut)
for 25 cycles
0% Ut
(100% dip in Ut)
for 5 sec.
Power frequency 30 A/m
(50/60 Hz)
magnetic field
IEC 61000-4-8
NOTE: Ut is the a.c. mains voltage prior to application of the test level.
electromagnetic immunity
Compliance Level
+/- 8 kV contact
+/- 2, 4, 8,
15 kV air
+/- 2 kV mains
supply lines
N/A
+/- 0.5, 1 kV
line(s) to line(s),
mains supply
+/- 0.5, 1, 2 kV
line(s) to earth,
mains supply
100% reduction
0.5 period at
8 angels
100% reduction
for 1 period
30% reduction
for 25 periods
100% reduction
for 5 sec.
30 A/m
Electromagnetic
environment -
guidance
If floors are covered
with synthetic material
the relative humidity
shall be least 30%.
Mains power quality
shall be that of a
typical commercial or
hospital environment.
Mains power quality
shall be that of a
typical commercial or
hospital environment.
Mains power quality
shall be that of a
typical commercial or
hospital environment.
If the use of the
system requires
continued operation
during power
mains interruptions
the system can
be powered
by the built in
rechargeable battery.
Power frequency
magnetic fields
should be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
