90 AVENTICS | PROFIBUS DP | R499050016–BDL–001–AE
Assembly
Fig. 5: Dimensioned drawing of valve system (bus coupler and valves), example (m = number of input/
output modules)

6.1.1 Dimensions

A + (60 x m)
B + (60 x m)
60 60 9
Each input/output module extends the valve system by 60 mm
(60 x m). The E end plate has an installation depth of 18 mm.
