AVENTICS | PROFIBUS DP | R499050016–BDL–001–AE

1.3.2 Symbols

The following symbols indicate information that is not relevant
for safety but that assists in comprehending the documentation.
Tab. 3: Meaning of the symbols
Symbol Meaning
If this information is disregarded, the product cannot be
used or operated optimally.
O
Individual, independent action
1. Numbered steps:
2.
3. The numbers indicate sequential steps.
1.4

Abbreviations used

Abbreviation Meaning
VS Valve system
GSD General Station Description
EP end plate End plate with electrical and pneumatic connections
P end plate End plate with pneumatic connection
E end plate End plate with electrical connections
