Kommunikation über EtherNet/IP
4.5 Unterstützte Objekte
Siemens Motor Data Object, Instance Number: 32D hex
Unterstützte Dienste
Klasse
• Get Attribute single
Tabelle 4- 17 Class Attribute
Nr.
1
2
3
Tabelle 4- 18 Instance Attribute
Nr.
2
3
6
7
8
9
10
11
12
13
14
15
19
92
Dienst Typ Name
get UINT16 Revision
get UINT16 Max Instance
get UINT16 Num of Instances
Dienst Typ Name
Get;Set UINT16 Commisioning state
Get INT16 Motor Type
Get;Set REAL Rated Current
Get;Set REAL Rated Voltage
Get;Set REAL Rated Power
Get;Set REAL Rated Frequency
Get;Set REAL Rated Temperature
Get;Set REAL Max Speed
Get;Set UINT16 Pole pair number
Get;Set REAL Torque Constant
Get;Set REAL Inertia
Get;Set REAL Base Speed
Get;Set REAL Cos Phi
Instanz
• Get Attribute single
• Set Attribute single
Wert / Erläuterung
p0010
p0300
p0305
p0304
p0307
p0310
p0605
p0322
p0314
p0316
p0341
p0311
p0308
Funktionshandbuch, 01/2016, FW V4.7 SP6, A5E34229197A AC
Feldbusse
