7 m
aInTenance
a
IR fIlTeR
The air filter prevents the penetration of dirt into the engine via the intake air.
Foreign bodies which penetrate via the intake air and settle between cylinder line or piston cause the piston to get
stuck or piston seizure which damage the engine and could have consequential damages in the main drive.
Close the choke valve before starting to work on the air filter in order to prevent dirt from penetrating into the car-
burettor.
- Remove the cover of the air filter housing and
- remove the foam insert.
- Clean the foam insert with petroleum or low viscosity machine oil (air filter oil, accessories).
If you want to clean the foam insert with a detergent and water, then rinse it thoroughly afterwards
Soap residues could get into the engine and damage the lubricating film.
Oil the air filter afterwards with air filter oil.
- Clean the air filter housing with a brush or with a moistened cloth.
Never drive without air filter!
B
RaKInG
Brake linings and the composite fiberglass brake disks wear off with time. Thus, the braking effect decreases as the
maximal brake pressure was set according to the thickness of new linings/brake disks.
If you observe that the braking effect is fading
- Check the thickness of the brake disks at the drive shaft and
- correct if necessary the position of the adjusting rings at the brake linkages.
c
leanInG
- After driving, clean the entire vehicle of dust and dirt, use compressed air and / or a special spray detergent.
Pay particular attention to the bearings. Occasionally, remove the wheels and clean the ball bearing from dust
and deposits.
After cleaning, the movable parts must be re-lubricated.
After having lubricated the bearings remove any leaking oil and grease, since this is where dust can settle
particularly well.
- Clean the cooling fins of the cooling head regularly with a toothbrush, in order to ensure an optimal heat
dissipation.
l
uBRIcaTIOn
All moveable and bedded parts must be lubricated with a low viscosity machine oil or spray grease after cleaning and
after each use.
c T
hanGInG yRes
- Protect the tyres against jumping off the rims or against slipping by gluing them on the rims. Let the super glue
run in the gap between wheels and rims.
In order not to have to change the rims if you need to change the wheels, wrap the outer side of the rims with fabric
insulating tape before gluing the wheels.
The bald tyres can be removed from the rims with the insulating tape.
-
Effect two to three small holes in each rim bed to allow air to escape and to maintain the damping effect of the tyres.
d
IsPOsal
Rechargeable NiMH rechargeable batteries are recyclable.
At the end of its service life, dispose of the product according to the relevant statutory regulations.
The user is legally obliged (battery regulation) to return used batteries and storage batteries. Do not dispose
of used batteries via the household rubbish.
Batteries / storage batteries containing harmful substances are marked with the following symbols which
point out that the disposal via the household rubbish is prohibited. The designations for the respective
hazardous heavy metals are : Cd = cadmium, Hg = mercury, Pb = lead (name on battery/rechargeable bat-
tery, eg under the rubbish bin icons on the left).
You can return used batteries / accumulators free of charge to any collecting point in your local authority,
in our stores or in any other store where batteries / accumulators are sold.
Thus, you comply with your legal obligations and make your contribution to environmental protection.
© REELY 08/07
/ d
IsPOsal
