ModBus: Parameteroversikt

Holding register Name
(Protocol)
Version
40001
communication
(0)
profile
40002 Wink service
(1)
Switch box type
40003
(2)
Bus command timer
40014
(13)
40015 Drives on/off
(14)
Control mode
40025
(24)
Current value
40026
(25)
Pump 1 mode
40041
(40)
Pump 2 mode
40042
(41)
Pump 3 mode
40043
(42)
