12
STEUERBEFEHLE
D Befehlstabelle (Fortsetzung)
Befehl Sub-Befehl
Daten
1A
05 0131
0132 0001 bis
9999
0133 01 bis 60 Send/read CW keyer repeat time
0134 28 bis 45 Send/read CW keyer dot/dash ratio
0135
0136
0137
0138
0139
0140 s. S. 166 Set/read FFT scope waveform color set for
0141
0142
0143
0144
0145
0146
0147
0148
0149 s. S. 166 Send/read received text font color for RTTY
0150 s. S. 166 Send/read transmitted text font color (RTTY)
0151 s. S. 166 Send/read time stamp text font color (RTTY)
0152 s. S. 166 Send/read text font color in TX buffer (RTTY)
0153
0154 s. S. 166 Set/read FFT scope waveform color set for
0155
163
Beschreibung
01
M1 selection for count up trigger channel
02
M2 selection for count up trigger channel
03
M3 selection for count up trigger channel
04
M4 selection for count up trigger channel
Send/read present number
(0001=1, 9999=9999)
(01=1 second, 60=60 seconds)
(28=1:1:2.8, 45=1:1:4.5)
00
2 milliseconds selection for rise time of the
transmitted CW envelope
01
4 milliseconds selection for rise time of the
transmitted CW envelope
02
6 milliseconds selection for rise time of the
transmitted CW envelope
03
8 milliseconds selection for rise time of the
transmitted CW envelope
04
10 milliseconds selection for rise time of the
transmitted CW envelope
00
Normal selection for paddle polarity
01
Reverse selection for paddle polarity
00
Straight selection for keyer type
01
BUG-KEY selection for keyer type
02
ELEC-KEY selection for keyer type
00
Mic. up/down keyer function OFF
01
Mic. up/down keyer function ON
00
RTTY decoder FFT scope averaging function
OFF
01
Number 2 selection for RTTY decoder FFT
scope averaging function
02
Number 3 selection for RTTY decoder FFT
scope averaging function
03
Number 4 selection for RTTY decoder FFT
scope averaging function
RTTY decoder
00
RTTY decode USOS function OFF
01
RTTY decode USOS function ON
00
„CR,LF,CR+LF" selection for RTTY decode
new line code
01
„CR+LF" selection for RTTY decode new
line code
00
OFF selection for RTTY diddle
01
BLANK selection for RTTY diddle
02
LTRS selection for RTTY diddle
00
RTTY encode USOS function OFF
01
RTTY encode USOS function ON
00
RTTY auto CR+LF by keyboard's [F12] OFF
01
RTTY auto CR+LF by keyboard's [F12] ON
00
RTTY time stamp OFF
01
RTTY time stamp ON
00
Local time selection for RTTY time stamp
01
Clock2 selection for RTTY time stamp
00
Frequency stamp for RTTY time stamp OFF
01
Frequency stamp for RTTY time stamp ON
decoder
00
PSK decoder FFT scope averaging function
OFF
01
Number 2 selection for PSK decoder FFT
scope averaging function
02
Number 3 selection for PSK decoder FFT
scope averaging function
03
Number 4 selection for PSK decoder FFT
scope averaging function
PSK decoder
00
±8 Hz selection for PSK AFC function tuning
range
01
±15 Hz selection for PSK AFC function
tuning range
Befehl Sub-Befehl
Daten
1A
05 0156
00
PSK time stamp OFF
01
PSK time stamp ON
0157
00
Local time selection for PSK time stamp
01
Clock2 selection for PSK time stamp
0158
00
Frequency stamp for PSK time stamp OFF
01
Frequency stamp for PSK time stamp ON
0159 s. S. 166 Send/read received text font color for PSK
decoder
0160 s. S. 166 Send/read transmitted text font color (PSK)
0161 s. S. 166 Send/read time stamp text font color (PSK)
0162 s. S. 166 Send/read text font color in TX buffer (PSK)
0163
00
LOW scan speed selection
01
HIGH scan speed selection
0164
00
Scan resume OFF
01
Scan resume ON
0165 0000 bis
Send/read VOX gain
0255
(0000=0%, 0255=100%)
0166 0000 bis
Send/read ANTI-VOX gain
0255
(0000=0%, 0255=100%)
0167 00 bis 20 Send/read VOX delay time
(00=0.0 sec, 20=2.0 sec)
0168
00
VOX voice delay function OFF
01
Short selection for VOX voice delay
02
Mid selection for VOX voice delay
03
Long selection for VOX voice delay
0169 0000 bis
Send/read NB level
0255
(0000=0%, 0255=100%)
0170 00 bis 09 Send/read NB depth
(00=1, 09=10)
0171 0000 bis
Send/read NB width
0255
(0000=1, 0255=100)
0172 0000 bis
Send/read MONITOR gain
0255
(0000=0%, 0255=100%)
0173 00 bis 05 Send/read time-out timer
( 00=OFF, 01=3 min, 02=5 min, 03=10 min,
04=20 min, 05=30 min)
0174 00 bis 06 Send/read audio output level at APF ON
(00=0 dB, 06=+6 dB)
0175 00 bis 05 Send/read the TX Delay setting (HF)
( 00=OFF, 01=10 ms, 02=15 ms, 03=20 ms,
04=25 ms, 05=30 ms)
0176 00 bis 05 Send/read the TX Delay setting (50 M)
( 00=OFF, 01=10 ms, 02=15 ms, 03=20 ms,
04=25 ms, 05=30 ms)
0177
00
Send/read the Shutdown function is Shut-
down
01
Send/read the Shutdown function is
Standby/Shutdown
0178
00
Send/read command to disable to output
the antenna controller status (frequency and
so on) from [REMOTE].
01
Send/read command to enable to output the
antenna controller status (frequency and so
on) from [REMOTE].
0179
00
Send/read the spectrum display type is Fill
01
Send/read the spectrum display type is
Fill+Line
0180 s. S. 166 Send/read spectrum line color
0181
00
Send/read waterfall set for spectrum scope
OFF
01
Send/read waterfall set for spectrum scope
ON
0182 00 bis 06 Send/read peak color level set for waterfall of
the spectrum scope
( 00=Grid 1, 01=Grid 2, 02=Grid 3, 03=Grid 4,
04=Grid 5, 05=Grid 6, 06=Grid 7)
06
s. S. 166 Send/read DATA mode with filter set
07
00
WIDE selection for SSB transmit bandwidth
01
MID selection for SSB transmit bandwidth
02
NAR selection for SSB transmit bandwidth
08
00
SHARP selection for DSP filter type
01
SOFT selection for DSP filter type
09
00
3 kHz roofing filter selection
01
6 kHz roofing filter selection
02
15 kHz roofing filter selection
0A
00
WIDE selection for manual notch width
01
MID selection for manual notch width
02
NAR selection for manual notch width
1B
00
s. S. 167 Send/read repeater tone frequency
01
s. S. 167 Send/read tone squelch frequency
Beschreibung
