Befehl Sub-Befehl
Daten
16
02
00
Preamp OFF
01
Preamp 1 ON
02
Preamp 2 ON
12
00
AGC FAST selection
01
AGC MID selection
02
AGC SLOW selection
22
00
Noise blanker OFF
01
Noise blanker ON
32
00
Audio peak filter OFF
01
Audio peak filter WIDE ON
(320 Hz is selected when SHARP APF is set)
02
Audio peak filter MID ON
(160 Hz is selected when SHARP APF is set)
03
Audio peak filter NAR ON
(80 Hz is selected when SHARP APF is set)
40
00
Noise reduction OFF
01
Noise reduction ON
41
00
Auto notch function OFF
01
Auto notch function ON
42
00
Repeater tone OFF
01
Repeater tone ON
43
00
Tone squelch OFF
01
Tone squelch ON
44
00
Speech compressor OFF
01
Speech compressor ON
45
00
Monitor function OFF
01
Monitor function ON
46
00
VOX function OFF
01
VOX function ON
47
00
BK-IN function OFF
01
Semi BK-IN function ON
02
Full BK-IN function ON
48
00
Manual notch function OFF
01
Manual notch function ON
4F
00
Twin peak filter OFF
01
Twin peak filter ON
50
00
Dial lock function OFF
01
Dial lock function ON
55
00
15 kHz roofing filter selection
01
6 kHz roofing filter selection
02
3 kHz roofing filter selection
56
00
SHARP selection for DSP filter type
01
SOFT selection for DSP filter type
57
00
WIDE selection for manual notch width
01
MID selection for manual notch width
02
NAR selection for manual notch width
58
00
WIDE selection for SSB transmit bandwidth
01
MID selection for SSB transmit bandwidth
02
NAR selection for SSB transmit bandwidth
17*
1
s. S. 166 Send CW messages
18
00
Turn OFF the transceiver
01
Turn ON the transceiver*
19
00
Read the transceiver ID
1A
00
s. S. 168 Send/read memory contents
01
s. S. 165 Send/read band stacking register contents
02
s. S. 165 Send/read memory keyer contents
03
00 bis 49 Send/read the selected filter width
( SSB, CW, PSK: 00=50 Hz, 40=3600 Hz;
RTTY: 00=50 Hz, 31=2700 Hz;
AM: 00=200 Hz, 49=10 kHz)
04
00 bis 13 Send/read the selected AGC time constant
( 00=OFF, 01=0.1/0.3 seconds,
13=6.0/8.0 seconds)
05 0001
s. S. 167 Send/read SSB RX HPF/LPF
0002
00 bis 10 Send/read SSB RX Tone (Bass) level
(00=–5, 10=+5)
0003
00 bis 10 Send/read SSB RX Tone (Treble) level
(00=–5, 10=+5)
0004
s. S. 167 Send/read AM RX HPF/LPF
*
Beim Senden in CW oder eingeschalteter Break-in-Funk-
1
tion sendet der Transceiver CW-Signale, die vom ange-
schlossenen PC kommen.
Der Power-ON-Befehl (18 01) steht nur im Stand-by-Mo-
*
2
dus zur Verfügung. Der Transceiver reagiert nur auf Steuer-
befehle von der [REMOTE]-Buchse.
Beschreibung
Befehl Sub-Befehl
1A
2
STEUERBEFEHLE
Daten
05 0005 00 bis 10 Send/read AM RX tone (Bass) level
(00=–5, 10=+5)
0006 00 bis 10 Send/read AM RX Tone (Treble) level
(00=–5, 10=+5)
0007 s. S. 167 Send/read FM RX HPF/LPF
0008 00 bis 10 Send/read FM RX tone (Bass) level
(00=–5, 10=+5)
0009 00 bis 10 Send/read FM RX Tone (Treble) level
(00=–5, 10=+5)
0010 s. S. 167 Send/read CW RX HPF/LPF
0011 s. S. 167 Send/read RTTY RX HPF/LPF
0012 s. S. 167 Send/read PSK RX HPF/LPF
0013 00 bis 10 Send/read SSB TX Tone (Bass) level
(00=–5, 10=+5)
0014 00 bis 10 Send/read SSB TX Tone (Treble) level
(00=–5, 10=+5)
0015 00 bis 10 Send/read AM TX Tone (Bass) level
(00=–5, 10=+5)
0016 00 bis 10 Send/read AM TX Tone (Treble) level
(00=–5, 10=+5)
0017 00 bis 10 Send/read FM TX Tone (Bass) level
(00=–5, 10=+5)
0018 00 bis 10 Send/read FM TX Tone (Treble) level
(00=–5, 10=+5)
0019 s. S. 167 Send/read SSB TX bandwidth for WIDE
0020 s. S. 167 Send/read SSB TX bandwidth for MID.
0021 s. S. 167 Send/read SSB TX bandwidth for NARROW
0022 0000 bis
Send/read DRIVE gain
0255
(0000=0%, 0255=100%)
0023 0000 bis
Send/read speech level
0255
(0000=0%, 0255=100%)
0024 0000 bis
Send/read CW sidetone level
0255
(0000=0%, 0255=100%)
0025
00
CW sidetone level limit OFF
01
CW sidetone level limit ON
0026 0000 bis
Send/read beep level
0255
(0000=0%, 0255=100%)
0027
00
Beep level limit OFF
01
Beep level limit ON
0028
00
Squelch mute effect OFF (squelch is fixed
open) for audio output from USB-B con-
nector
01
Squelch mute effect ON for audio output
from USB-B connector
0029 0000 bis
Send/read modulation level for audio
0255
input to USB-B connector (0000=0%,
0255=100%)
0030
00
[MIC] selection for MOD input connector
during DATA OFF
01
[ACC] selection for MOD input connector
during DATA OFF
02
Both [MIC] and [ACC] selection for MOD
input connector during DATA OFF
03
[USB] selection for MOD input connector
during DATA OFF
0031
00
[MIC] selection for MOD input connector
during DATA1
01
[ACC] selection for MOD input connector
during DATA1
02
Both [MIC] and [ACC] selection for MOD
input connector during DATA1
03
[USB] selection for MOD input connector
during DATA1
0032
00
[MIC] selection for MOD input connector
during DATA2
01
[ACC] selection for MOD input connector
during DATA2
02
Both [MIC] and [ACC] selection for MOD
input connector during DATA2
03
[USB] selection for MOD input connector
during DATA2
12
Beschreibung
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
160
