5.6

Using Tube Sets

The Aquilex Fluid Control System is designed for use with sterile disposable in-
flow and outflow tube sets.
Each inflow tube set is equipped with tube set recognition technology. An RFID
transponder detects the type of tube, whether it has been used, and its reliability
automatically. The pump display indicates this information. This eliminates acci-
dental reuse of tube sets on more than one patient (see Chapter 5.7, Tube Over-
view).
WARNING!
Visual inspection of the tube set
Before the operation, perform a visual inspection of the tube set and its packag-
ing. Damaged tube sets or tube sets from damaged packagings may not be used.
WARNING!
Reprocessing of sterile disposable products
Reuse of inflow or outflow tube can cause an infection hazard for patients and/
or users as well as impair of product functionality. Contamination and/or im-
paired functionality of the system can cause risk of injury, illness, or death. Do
not re-process or reuse single-use inflow or outflow tube sets.
NOTE!
Comply with national disposal and hygiene rules when disposing of tubes, col-
lected fluid, and the containers or containers.
5.7

Tube Overview

Three different tube sets are necessary to operate the system. The following ta-
ble lists each type of tube set and its application.
Article num- Description
ber
AQL-110 Aquilex Fluid Control System inflow tube set, disposable,
sterilized using ethylene oxide
AQL-111 Aquilex Fluid Control System outflow tube set, disposable,
sterilized using ethylene oxide
AQL-112 Complete tube set (inflow and outflow) disposable, sterilized
using ethylene oxide
AQL-114 Aquilex Fluid Control System high and low vacuum tube set:
re-usable, non-sterile
Table 5-1
System Operation
Tube set recognition
en
23
