Information
Manufacturer
Machine
Type / Item number
Serial number / Engine number
Construction year
Important technical data:
Rated voltage [V]
Rated frequency [Hz]
Rated speed [1/min]
Rated current [A]
Rated power factor cos φ [–]
Rated power 1~ [kVA]
ISO class
Protection type
Sound power level L
Mass [kg]
3.5

Components and protective devices

The genset is fitted as standard with some protective devices that enable safe and
economical operation. These are introduced in brief below.
3.5.1

Automatic low-oil shutoff function

The automatic low-oil shutoff function prevents engine damage caused by insufficient oil
by permanently monitoring the oil level. As soon as the sensor signals a low oil level, the
engine is shut down by cutting the ignition. The genset stops even though the engine switch
remains in the I position.
The indicator lamps display the following signals when the automatic low-oil shutoff
function is triggered:
ƒ OIL ALERT: The oil warning indicator lights up yellow.
ƒ OUTPUT INDICATOR: The operation indicator is off.
The effects of the automatic low-oil shutoff function are as follows, depending on the
operating state:
ƒ The genset cannot be started:
– No oil in the engine (as-delivered state).
– Insufficient oil in the engine.
– The genset is at such an angle that the sensor indicates low oil even though the oil
level would be sufficient in a horizontal position.
Subject to change.
Value
Metallwarenfabrik Gemmingen GmbH
[dB(A)]
WA
EISEMANN
BSKA 2V RSS
75050 Gemmingen, Germany
Tel.: +49 (0) 7267 / 806-0
Genset
(see headline)
(individual)
(from 2018)
230 V 1
~
50
4500
7
1.0
1.6
F
IP23
93
21.5
904217 – 2018-11
