1 Feet with vibration dampers
2 Safety labelling, in accordance with DIN 14685-3 with the following content:
ƒ Warning notice for explosion protection
ƒ Details of the maximum permissible line lengths
ƒ Safety-relevant notices
ƒ Quick guide to genset operation
3 Starter handle with pull cable (recoil starter)
4 Engine switch with integrated fuel valve
5 Robust side housing cover:
ƒ Left side: Access to starter unit and fuel system.
ƒ Right side: Access to spark plug connector, air filter and oil filler neck.
6 Rating plate with performance details
7 Symbols for identifying relevant hazards, prohibitions and protective measures (in
accordance with DIN 4844-2 and DIN EN ISO 7010)
8 Ergonomic carrying handle incl. insulation against heat and cold, non-slip rubberised
9 SMART THROTTLE (ON / OFF) – switches economy mode on and off, see
"3.5.2 Economy mode" on page 82
10 PILOT LAMP – 3 indicator lamps for showing the operating state:
ƒ Oil warning indicator (OIL ALERT):
– Off: Normal mode.
– Yellow: Oil level too low.
ƒ Overload alert (OVERLOAD ALERT):
– Off: Normal mode.
– Yellow: Overload or short circuit at the consumer, see
overload protection" on
ƒ Operation indicator (OUTPUT INDICATOR):
– Green: Normal mode.
– Off: The genset is switched off or overloaded.
11 230 V AC socket (earthing contact in acc. with DIN 49440/441), protection type IP68,
incl. bayonet cap with retaining strap
12 DC socket 12 V DC, 8.3 A incl. automatic circuit breaker with safety switch
13 Operating hours meter
14 USB charger connection 5 V DC, 2 A (socket USB standard A)
15 Earthing screw
16 Choke lever, see
"3.5.3 Choke" on page 82
17 Front housing cover with control panel and ventilation slots
18 Rubber tab with access to the spark plug
19 Exhaust silencer and exhaust outlet
20 Rear housing cover with protective grating and ventilation slots
21 Cover with access to the oil filler neck
22 Fuel tank fill level indicator
23 Fuel tank filler neck incl. tank cap with retaining strap
Subject to change.
page 84.
"3.5.5 Normal mode and
