Technische Daten
Leistung SIBA Littelfuse
[kW] Typ RK1 Typ RK1
1,1 5017906-006 KLS-R-6
1,5–2,2 5017906-010 KLS-R-10
3 5017906-016 KLS-R-15
4 5017906-020 KLS-R-20
5,5 5017906-025 KLS-R-25
7,5 5012406-032 KLS-R-30
11–15 5014006-040 KLS-R-40
18 5014006-050 KLS-R-50
22 5014006-063 KLS-R-60
30 2028220-100 KLS-R-80
37 2028220-125 KLS-R-100
45 2028220-125 KLS-R-125
55 2028220-160 KLS-R-150
75 2028220-200 KLS-R-200
90 2028220-250 KLS-R-250
Tabelle 7.15 3x380-480 V, Baugrößen A, B und C
1) A50QS-Sicherungen von Ferraz-Shawmut können A50P-Sicherungen ersetzen.
3x525–600 V
Bussman
Leistun Bussmann
n
g [kW] Typ J
Typ RK1
1,1 KTS-R-5 JKS-5
1,5–2,2 KTS-R-10 JKS-10
3 KTS-R15 JKS-15
4 KTS-R20 JKS-20
5,5 KTS-R-25 JKS-25
7,5 KTS-R-30 JKS-30
11–15 KTS-R-35 JKS-35
18 KTS-R-45 JKS-45
22 KTS-R-50 JKS-50
30 KTS-R-60 JKS-60
37 KTS-R-80 JKS-80
45 KTS-R-100 JKS-100
55 KTS-R-125 JKS-125
75 KTS-R-150 JKS-150
90 KTS-R-175 JKS-175
Tabelle 7.16 3x525-600 V, Baugrößen A, B und C
MG16G203
Projektierungshandbuch
Empfohlene maximale Sicherung
Ferraz Ferraz
Shawmut Shawmut
Typ CC Typ RK1
ATM-R-6 A6K-6-R
ATM-R-10 A6K-10-R
ATM-R-15 A6K-15-R
ATM-R-20 A6K-20-R
ATM-R-25 A6K-25-R
ATM-R-30 A6K-30-R
– A6K-40-R
– A6K-50-R
– A6K-60-R
– A6K-80-R
– A6K-100-R
– A6K-125-R
– A6K-150-R
– A6K-200-R
– A6K-250-R
Empfohlene maximale Sicherung
Bussmann Bussmann Bussmann
Typ T Typ CC Typ CC
JJS-6 FNQ-R-5 KTK-R-5
JJS-10 FNQ-R-10 KTK-R-10
JJS-15 FNQ-R-15 KTK-R-15
JJS-20 FNQ-R-20 KTK-R-20
JJS-25 FNQ-R-25 KTK-R-25
JJS-30 FNQ-R-30 KTK-R-30
JJS-35 – –
JJS-45 – –
JJS-50 – –
JJS-60 – –
JJS-80 – –
JJS-100 – –
JJS-125 – –
JJS-150 – –
JJS-175 – –
