Inserting an image from a USB flash drive
⇒ Select the USB flash drive in the split screen main menu (Fig. 20) or the split
screen sub-menu (Fig� 21)�
⇒ Select using the left mouse button�
♦ A list of the files on the USB flash drive is displayed in the menu.
⇒ Use the mouse wheel to select a file.
♦ A preview of the file is displayed in a corner of the screen.
⇒ Select the desired file using the left mouse button.
♦ The file is inserted and fixed in the opposite corner.
♦ The file name of the selected image is displayed in green.
⇒ Select another file using the mouse wheel or close the file list using the right
mouse button�
Inserting screenshot
⇒ Select the screenshot item in the split screen sub-menu (Fig� 21)�
⇒ Select using the left mouse button�
♦ An hour glass icon appears on the monitor while the screenshot is being
created�
♦ The screenshot taken is inserted into the selected corner of the monitor�
Black & white / color sub-menu
The following combinations are possible:
• The main image in black & white, the inserted image in color�
• The main image in color, the inserted image in black & white�
• Both images in black & white�
• Both images in color�
• Exit: Closing split screen menu�
The selected combination is displayed in green�
Sub-menus - settings
The following selections are possible in this menu:
• Insert the image in the right or left corner of the monitor�
If an image is inserted from a USB flash drive, a preview of the selected file
appears in the opposite corner of the monitor, see „Inserting image from a
USB flash drive".
• Changing the size of the inserted image (3 sizes + full screen)�
• Displaying system information�
• Exit: Closing split screen menu�
Full screen display can also be selected from the image size options. In this
case, the 2D or 3D image is no longer visible.
5.8.1 System information
The system information sub-menu provides information on
• The system name
• The version of the software included
If the EASY view+ 3D is connected to a network, the following are additionally
displayed:
• IP address
• Hostname
This information is necessary if the EASY view+ 3D is to be integrated into a
network in order to gain access to the images on the USB flash drive via this
network�
