Mains connection
► Do not remove earth or protective conductor connection from the mains plug of the power supply
unit.
► Unplug the power supply unit when the monitor is not used for an extended period of time, or if
the power cord, power plug, or monitor housing is damaged.
Caution
► Do not try to open the product. Any attempt to open the product or remove the cover will void the
warranty and may result in serious injury.
6.2 Connections
40 DC 12 V 3�33 A
41 DVI input
42 VGA input
6.3 Operation and settings
8
Power switch
43 Menu, opens the monitor menu
44 Signal source selection� Reduce the selected value in the
monitor menu
45 Adjust brightness� Increase the selected value in the monitor
menu
46 AUTO, automatic horizontal and vertical adjustment of the
image� Also to exit the monitor menu
6.4 Monitor Menu
Color
Contrast
Adjust screen contrast (difference between light and
dark regions of the image)�
Brightness
Adjust the brightness of the image�
Color Temp.
Select between different, preset color temperatures or
set your own custom parameters�
(9300/6500/5500/USER)�
Auto Adjust (not selectable).
Color Adjust (not selectable).
The settings under this menu item are fixed and can-
not be changed�
The menu item cannot be selected�
40
43
- 17 -
41 42
Fig. 28
44 45 46 8
Fig. 29
Fig. 30
Fig. 31
