RCM BYTE I Handbuch Für Gebrauch Und Wartung Seite 60

The scrubber-dryer must be cleaned as soon as work is completed.
!
DANGER!
CHECK THAT THE SCRUBBER-DRYER IS SWITCHED OFF BEFORE
STARTING TO CLEAN IT.
• Stop brush rotation and suction by pressing the relevant buttons located on the start-up panel
(see " Components - Point 1 and 2".
• The electrical system for battery-operated machines must not be powered; turn the key to the
"0" position and then remove it.
• For "230V.AC cable-operated" machines, disconnect the cable from the power outlet.
!
CAUTION! MACHINES EQUIPPED WITH A BATTERY CHAR-
GER ON BOARD
WHEN CLEANING THE MACHINE, TAKE CARE THAT NO WATER
ENTERS THE BATTERY CHARGER.
Cleaning the brush
For maximised brush cleaning, check the brush wear and tear; if the brush is in good condition, remove
it and clean it under a jet of water. If the brush is worn and must be replaced, see "Maintenance - brush
removal and replacement. (fi g.8). "
Cleaning the squeegee
The squeegee must be perfectly clean for best drying. Proceed as follows:
• Lift the squeegee by pulling up lever 1.
• Remove the squeegee by following the instructions in reverse order as described in chapter "Pre-
paring the scrubber-dryer – fi tting the squeegee".
• Carefully clean the inside of the squeegee under a jet of water.
• Check the squeegee wheels and turn or even replace them if they are worn out, or clean them
under a jet of water if they are still in good condition.
• Fit the squeegee back in place.
Cleaning the recovery tank (dirty water) and fi lter
• Empty the recovery tank 2 completely as described in the "End work" section.
• Lift the recovery tank cover and remove the underlying fi lter 3, then clean it under a jet of water.
• Clean the inside of tank 2 and hose 2a under a jet of water.
• Fit everything back in place.
!
CAUTION!
RECOVERY TANK AND FILTER CLEANING SHALL BE PERFORMED
WHEN THE TANK IS FULL, AT THE END OF WORK AND IF THE MA-
CHINE IS NOT USED FREQUENTLY.
Cleaning the solution tank (clean water) and fi lter
!
CAUTION!
SOLUTION TANK (CLEAN WATER) 4 CLEANING SHALL BE PER-
FORMED WHEN THE MACHINE IS NOT USED FREQUENTLY.TO
AVOID THE BUILD-UP OF DETERGENT INSIDE THE TANK, DO NOT
LEAVE THE SOLUTION (H2O+DETERGENT) INSIDE THE TANK FOR
LONG TIME.
• Remove cap 5 for emptying, clean the tank with a jet of water entering through mouth 6.
• Unscrew cap 7, remove fi lter 7a and clean it.
!
DANGER! FROST HAZARD
WITH TEMPERATURES OF 0°C OR BELOW, CHECK AND EVEN-
TUALLY FULLY REMOVE WATER FROM TANKS AND HOSES AT
THE END OF EACH JOB OR IF THE MACHINE IS UNUSED FOR A
CERTAIN PERIOD OF TIME.
CLEANING THE SCRUBBER-DRYER
!
CAUTION!
NEVER WASH THE MACHINE WITH WATER JETS.
2a
7a
60
FIG.7
1
7
6
3
2
4
5
