10. Go to the Connection tab and activate Connect
when this network is in range.
11. Exit the dialog with OK.
The network should now appear in the network list
and it should (automatically) appear after the network
name CX22-W.
12.Go to the General tab, select Internet Protocol
(TCP/IP) in the list and click on Properties.
13.In the following dialog, activate Obtain an IP address
automatically and Obtain DNS server address
automatically.
14. Close all dialogs for Wireless Network Connection
with OK or Close.
7.3.6
Setting up a connection via WLAN and Adhoc
network
1. Start the PC from where the connection is to be set
up.
2. Right-click on the symbol for WLAN displayed in the
notification area of the Windows task bar and select
Display available wireless networks.
3. Check that the PC is connected with the "CX22-W"
network or with the network with the name given
above under Network name (SSID). If necessary,
wait approx. 2 minutes after switching on the CX22-W
until the connection has been set up.
4. Launch the "QuantumX Data Recorder Assistant"
program: Windows Start menu -> All programs ->
HBM -> QuantumX Data Recorder Assistant
(Windows
XP: Windows Start menu -> Programs
-> HBM -> QuantumX Data Recorder Assistant).
