1. CX22-W and PC are connected directly via an
Ethernet cable.
For a detailed description, see Section 7.1, Page 29.
2. The CX22-W data recorder is connected with an
Ethernet network (generally automatic assignment of
network configuration via DHCP, Dynamic Host
Configuration Protocol).
For a detailed description, see Section 7.2, Page 33.
3. The CX22-W data recorder is connected via WLAN
(CX22-W only).
For a detailed description, see Section 7.3, Page 36.
The initial configuration of a CX22-W with WLAN must be
implemented either with monitor and keyboard (see
Section 6.2) or via a connection with Ethernet cable. You
can then also activate the WLAN interface during this
configuration and enter the parameters for a WLAN
connection.
Important
Wait approx. 1 minute after switching on the CX22-W
before setting up a connection, so that the boot process
is complete and the module is ready. Otherwise you may
receive an error message that the device could not be
found.
To facilitate setting up a CX22-W connection with
unknown settings, you can use the HBM program
"QuantumX Data Recorder Assistant". The settings
required are described in Chapter 7.1 from Page 29.
If you do not want to use the program, you can also set
up a direct remote desktop connection (default program
of the Windows operating system), see Chapter 7.4 from
