CX22-W
Start
Pre-trigger
A3169-5.0_en/de
Fig. 10.1 Starting and stopping measurement with a trigger.
All the measured values between start and stop, as
well as those in the pre-trigger and post-trigger
periods are recorded
11. Click on Data storage (Settings group) and specify
the settings for saving the data after or during
measurement. We recommend using the setting
Automatically on DAQ termination for Data
saving. Otherwise a monitor must be connected
during measurement in order to save the data.
12.Generate visualization if a monitor is connected.
13.Save your DAQ project: menu File -> Save ->
Project.
14. Start your DAQ project via Start DAQ in the
Measurement group.
If you have not created a visualization, you will be
asked if one of the default settings for visualization
should be used. Click on Measure without display if
a monitor is not connected during measurement.
The CX22-W measurement mode is activated. If you
have defined a start trigger, e.g. the START/STOP-
button, this will be waited for, if not, measurement will
start. The "RECORDING" LED flashes while waiting
for the start trigger and glows continuously as soon as
measurement starts.
Stop
Post-trigger
