5.1

Procedure for removing the CF card

Note
Do not replace the CF card when the CX22-W is
switched on.
Otherwise the CX22-W or the CF card could be damaged
or, if measurement data are being recorded, this could
cause all the data of the test to be lost.
Switch the CX22-W off before replacing the CF card.
1. Undo the retaining screw for the CF card (Fig. 4.2 on
Page 16). The screw must not be removed, it should
just be loosened.
2. Swivel the cover plate upwards to expose the slot for
the CF card.
3. Use a blunt object, e.g. a ball-point pen, to press the
ejection button on the right in the CF card slot
(Fig. 4.2).
4. Remove the CF card.
5. Read Section 5.2, this describes the insertion of the
CF card. The CX22-W should not be operated without
a CF card, as no data can be stored.
