CX22-W
A3169-5.0_en/de
3. Call up the catman
go to Program start (Group System).
4. Select an Existing DAQ project for Start mode and
choose the project created above in the DAQ project
line.
5. Activate the option Execute first DAQ job
automatically.
6. Go to DAQ channels in the Group Channels and
sensors.
7. Activate the option Deactivate defective channels
and continue with DAQ (If channel initialization
fails).
8. Exit the dialog by clicking on OK.

9. Exit catman
10. In the start screen, click on Settings.
11. On the General tab, activate the option Launch DAQ
software (catmanEASY) at CX22-W startup and
click on OK.
12.Click on Commit changes and reboot to
permanently save the new settings.
This project will then be automatically started when the
CX22-W is switched on again. If the power supply is
interrupted during measurement, the project will be
reloaded and measurement continued when the power
supply is restored. The module restart, up to the
continuation of measurement, will require approx. 3
minutes, dependent on the number of connected devices
and channels.
The data already present in the catman
temporary data storage are not lost if the power supply is
interrupted. Any additional files will be assigned a counter
at the end of the file name.

EASY options (File menu) and
EASY.

EASY
