HBM QUANTUM X Bedienungsanleitung Seite 47

CX22-W
A3169-5.0_en/de
5. Click on Find CX22-W.
6. The CX22-W data recorder appears in the top list, the
current addresses of the interfaces are also displayed
(also see Fig. 7.6 on Page 40).
7. Select the CX22-W in the top list.
8. Click on Remote connect using WLAN.
9. If Windows queries whether a connection to the
remote computer should be set up, confirm the
connection. We recommend activating the option Do
not ask about connection to this computer again
(see Fig. 7.2 on Page 32). Depending on the
configuration of your Windows operating system,
another query as to whether the connection should be
set up may be displayed (identity of the remote
computer). If necessary, activate the option to prevent
the query (see Fig. 7.3 on Page 32).
The connection with the CX22-W data recorder will
now be implemented and you must register with the
device (Windows login dialog). Enter HBMCX22 as
the User name and hbm as the Password. The text
for the Password must be in lower case.
Tip
If setting up the connection in the Adhoc network takes
too long for you, you can also assign permanent IP
addresses to the CX22-W and PC. Refer to Section 7.1
on Page 29 (contains an example of permanent IP
addresses). This makes connection set up faster.
47
