Draining water from the reservoir (Continued)
EN
2. Dispose of the water per hospital protocol.
3. Replace the reservoir.
Note: Make sure that the reservoir is dry before you store the product.

Draining water from the controller and hoses

Make sure that the controller and all components are dry before you store the product. Make sure to drain the hoses
before you store them.
1. Place the controller over a floor drain.
2. Remove the reservoir and pull up on the controller drain plug (A) to open the drain
3. Connect a hose to each port.
a. If you have Colder style connector hoses, attach the service tool adapter hose (8001-999-017).
b. If you have Clik-Tite hoses, make sure that the connectors and clamps are open
4. Raise all the hoses completely above the connection ports on the controller.
5. Allow the product to drain for a minimum of two minutes.
6. Push down on the drain plug to close the drain.
7. Replace the reservoir.
1-36
Operation
A
Figure 1-21: Drain plug
Figure 1-22: Clik-Tite open
8001-109-005 REV B
(Figure 1-21 on page 1-36).
(Figure 1-22 on page 1-36).
