Product system

EN
1 Human machine interface (HMI) system
2 Physical boundary
3 Patient system
4 Patient temperature port
5 Fluid delivery system
1-12
Introduction
Figure 1-3: Altrix system - controller with thermal transfer devices
Figure 1-4: Closed loop system
8001-109-005 REV B
6 Controls
7 Flow system
8 Energy transfer system
9 Water flow
10 Signals
