Product functions (Continued)
EN

Graphical user interface icons

Icon

Product alarms

Audible alarms work in conjunction with the display.
1-16
Introduction
Name
Cooling therapy
Warming therapy
Current therapy duration
Total duration
Visual and audible tests
Target patient or water temperature
Medium: patient temperature increases at a rate of 4.0° C in 12 hours (0.33° C/ hour).
Maximum: water temperature approaches water target as fast as possible
Minimum: patient temperature increases at a rate of 4.0° C in 24 hours (0.17° C/hour).
Set Custom: patient temperature increases at a customized temperature and time period the
operator selects. The temperature increases 0.05° C/hour to 0.5° C/hour
Maximum: water temperature approaches water target as fast as possible
Medium: water is cooled to target, with a max of 15.0° C difference between the patient and
the water temperature
Minimum: water is cooled to target, with a max of 10.0° C difference between the patient and
the water temperature
