Product functions (Continued)
EN
Icon
Notes
• If not specified above, make sure that you tap and release the buttons or icons for your selection to register with the
system.
• The Light sensor (non selectable)
¹Breathe: The brightness of the button or icon will go to a low light and then increase to a bright light. This cycle
•
repeats.

Visual indicators

When the visual indicators are solid green, this indicates that the function is stabilized. The visual indicators breathe to
indicate that the controller is at the intermediate target.
1-14
Introduction
Name
Increase
Decrease
Back
Edit settings, Exit, or Cancel
Confirm selection
Next or More
Page indicators (may also
appear vertical)
Settings
Graph
Help
, dims or brightens the LCD based on the amount of light in the room.
Function
Increases the water or patient temperature by 0.1° for cooling or
warming temperature
Note: Press and hold the increase button to move the
temperature up faster.
Decreases the water or patient temperature by 0.1° for cooling
or warming temperature
Note: Press and hold the decrease button to move the
temperature down faster.
Returns to the previous screen or cancel an operation
Edit current settings, exit, or cancel
Accepts the selected settings
Changes to the next screen, option, or setting
Indicates that there is more than one page associated with the
screen topic for the page that is currently displayed
Displays the summary of the current, visual / audible, language,
or primary probe settings
Graphical display of the selected items such as patient
temperature, target temperature, water temperature, and power
level
Displays contextual help screens for therapies, navigation,
buttons, and alarm screens. This button breathes to allow the
user to view the alarm screen.
