Danfoss VLT AQUA Drive FC 202 Programmierhandbuch Seite 287

Parameterlisten
Para Parameterbeschreibung
meter
num–
mer
16-54 Istwert 1 [Einheit]
16-55 Istwert 2 [Einheit]
16-56 Istwert 3 [Einheit]
16-58 PID-Ausgang [%]
16-59 Adjusted Setpoint
16-6* Anzeig. Ein-/Ausg.
16-60 Digitaleingänge
16-61 AE 53 Modus
16-62 Analogeingang 53
16-63 AE 54 Modus
16-64 Analogeingang 54
16-65 Analogausgang 42
16-66 Digitalausgänge
16-67 Pulseingang 29 [Hz]
16-68 Pulseingang 33 [Hz]
16-69 Pulsausg. 27 [Hz]
16-70 Pulsausg. 29 [Hz]
16-71 Relaisausgänge
16-72 Zähler A
16-73 Zähler B
16-75 Analogeingang X30/11
16-76 Analogeingang X30/12
16-77 Analogausgang X30/8 [mA]
16-78 Analogausgang X45/1 [mA]
16-79 Analogausgang X45/3 [mA]
16-8* Anzeig. Schnittst.
16-80 Bus Steuerwort 1
16-82 Bus Sollwert 1
16-84 Feldbus-Komm. Status
16-85 FC Steuerwort 1
16-86 FC Sollwert 1
16-87 Bus Readout Alarm/Warning
16-89 Configurable Alarm/Warning Word
16-9* Bus Diagnose
16-90 Alarmwort
16-91 Alarmwort 2
16-92 Warnwort
16-93 Warnwort 2
16-94 Erw. Zustandswort
16-95 Erw. Zustandswort 2
16-96 Wartungswort
16-97 Alarm Word 3
16-98 Warning Word 3
MG20OB03
Programmierhandbuch
Werkseinstellung 4 Parame-
tersätze
0 ProcessCtrlUnit All set-ups
0 ProcessCtrlUnit All set-ups
0 ProcessCtrlUnit All set-ups
0 % All set-ups
0 ProcessCtrlUnit All set-ups
0 N/A All set-ups
[0] Strom All set-ups
0 N/A All set-ups
[0] Strom All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Danfoss A/S © 05/2018 Alle Rechte vorbehalten.
Ändern Konvertie-
während des rungsindex
Betriebs
TRUE -3
TRUE -3
TRUE -3
TRUE -1
TRUE -3
TRUE 0
TRUE -
TRUE -3
TRUE -
TRUE -3
TRUE -3
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE -3
TRUE -3
TRUE -3
FALSE -3
FALSE -3
TRUE 0
TRUE 0
TRUE 0
FALSE 0
FALSE 0
FALSE 0
FALSE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
FALSE 0
FALSE 0
Datentyp
Int32
Int32
Int32
Int16
4 4
Int32
Uint16
Uint8
Int32
Uint8
Int32
Int16
Int16
Int32
Int32
Int32
Int32
Uint16
Int32
Int32
Int32
Int32
Int16
Int16
Int16
V2
N2
V2
V2
N2
Uint16
Uint16
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
285
