Parameterbeschreibung
8-17 Configurable Alarm and Warningword
Array [16]
Wählen Sie die Bedeutung eines bestimmten Bit im konfigu-
rierbaren Alarm- und Warnwort. Das Wort hat 16 Bits (0–15).
Option:
3 3
[14]
[17]
[19]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[34]
[36]
[40]
[41]
[45]
[47]
[58]
[59]
[60]
[61]
[62]
[64]
[65]
[66]
[68]
[73]
[76]
[77]
[163]
[165]
[10002]
[10004]
[10007]
[10008]
[10009]
[10010]
[10011]
[10012]
[10013]
[10014]
[10016]
[10017]
[10026]
[10027]
[10028]
[10029]
114
Earth fault warning
Controlword timeout warning
Discharge temp high warning
Internal fans warning
External fans warning
Brake resistor short circuit warning
Brake powerlimit warning
Brake chopper short circuit warning
Brake check warning
Heatsink temperature warning
Motor phase U warning
Motor phase V warning
Motor phase W warning
Fieldbus communication warning
Mains failure warning
T27 overload warning
T29 overload warning
Earth fault 2 warning
24V supply low warning
AMA internal fault warning
Current limit warning
External interlock warning
Feedback error warning
Frequency max warning
Voltage limit warning
Controlboard overtemp warning
Heatsink temp low warning
Safe stop warning
Safe stop autorestart warning
Power unit setup warning
Reduced powermode warning
ATEX ETR cur limit warning
ATEX ETR freq limit warning
Live zero error alarm
Mains phase loss alarm
DC overvoltage alarm
DC undervoltage alarm
Inverter overload alarm
ETR overtemperature alarm
Thermistor overtemp alarm
Torque limit alarm
Overcurrent alarm
Earth fault alarm
Short circuit alarm
CTW timeout alarm
Brake powerlimit alarm
Brakechopper shortcircuit alarm
Brake check alarm
Heatsink temp alarm
