GEAR HUB WITH DISK BRAKE
1. Use a 5-mm Allen wrench to undo the two screws
on both sides of the frame
2. Use a 5-mm Allen wrench to undo the fixing screw
CD) on both sides.
3. Now shift the rear wheel to adjust the chain tension (Fig. CE).
To do so, screw in the fixing screw
rect position has been reached. Make sure that the wheel is
straight when seated in the holder and that the chain is pro-
perly tensioned (see Checking the chain tension chapter)
4. Tighten the screws
tions chapter).
All manuals and user guides at all-guides.com
(Fig. CD) until the cor-
2
(Fig. CD) firmly (see Torque specifica-
1
CD
(Fig. CD)
1
(Fig.
2
1
CE
CHAIN
1
2
3
EN 69
