DRIVE SYSTEM
DISPLAY OF REMAINING RANGE
1. To display the approximate remaining range
LED display. (The e-bike must be switched on beforehand.)
EASY CONTROL DISPLAY
Sie bedienen das Antriebssystem mittels des Easy-
Control-Steuerdisplays an der linken Seite des Lenkers
(Abb. AX).
Die Displayhelligkeit wird automatisch mittels eines
Helligkeitssensors geregelt. Die Lichtanlage wird
ebenfalls hierüber automatisch gesteuert (s. auch
Kapitel Beleuchtung).
Plus button +
1
Speed level
2
Speed display
3
Battery charge state
4
Minus button –
5
ON/OFF button
6
SWITCHING THE DRIVE SYSTEM ON/OFF
1. Press button (Fig. AY) on the battery until the charge state indicator lights up (only for sys-
1
EN 46
, briefly press button
1
Use this button to increase the pedalling assistance in single-level incre-
ments. Holding down the button for approx. 3 seconds will switch the ligh-
ting on or off manually.
The LED lights indicate which pedalling assistance level is active.
The display indicates the current speed in km/h.
The LED lights indicate the current charge state of the battery.
Use this button to decrease the pedalling assistance in single-level incre-
ments. Holding down the button for a few seconds will activate the pushing
aid.
This button switches the drive system on and off.
(Fig. AW) on the mini
4
AX
1
2
3
4
5
6
