HANDLEBAR
SPEED LIFTER
The speed lifer will enable you to set the handlebar at the
desired height within seconds or to practically turn it in by
90° for transport and storage.

SETTING THE HEIGHT

1. Release the lever
2. Push the handlebar to the desired height.
3. Push the quick-clamp lever
pletely flush (s. also chapter Quick-clamp).

TURN IN THE HANDLEBAR

1. Release the lever
2. Push the safety lever up
3. Now turn in the handlebar.
If you want to align the handlebar with the riding position again,
proceed as follows:
1. Turn in the handlebar in the cycling direction.
2. Push the safety lever
3. Push the quick-clamp lever
flush (s. also chapter Quick-clamp).
EN 20
(fig. N) of the quick-clamp.
1
(fig. N) back until it is com-
1
(fig. N) of the quick-clamp.
1
(fig. N).
2
(fig. N) down completely.
2
(fig. N) back until it is completely
1
N
2
1
