STEM WITH ANGLE ADJUSTMENT
SETTING THE POSITION AND HEIGHT
• The stem must not be pulled out beyond the mark
insertion depth
ranty if this is not observed!
DANGER
1. Loosen the clamp screw
wrench.
2. You can now set the handlebar position or the stem height. Al-
ways observe the mark of the minimum insertion depth.
3. Tighten the clamp screw
specification (s. chapter Torque specifications).
SET STEM ANGLE
1. Loosen the lateral clamp screw
agonal socket wrench.
2. Now adjust the desired angle at the stem.
3. Then tighten the clamp screw
the torque specification (s. chapter Torque specifications).
SETTING THE HANDLEBAR INCLINATION
1. First loosen the clamp block screw
bar attachment with a 4 or 5 mm hexagonal socket wrench.
2. Adjust the inclination angle of the handlebar.
3. Tighten the clamp block screw
Torque specifications).
4. Turn the handlebar attachments (e.g. brake lever) back to the
starting position if necessary.
All manuals and user guides at all-guides.com
(fig. D) must not be visible. Danger of damage and accidents! - No war-
2
(fig. D) with a 6 mm hexagon socket
1
(fig. D) again according to the torque
1
(fig. D) with a 6 mm hex-
3
(fig. D) again according to
3
(fig. E) of the handle-
1
(fig. E) again well (s. chapter
1
(fig. D)! The mark of the minimum
2
D
3
E
1
1
HANDLEBAR
1
2
1
1
EN 17
