FOLDING FRAME • SUSPENSION FORK

FOLDING FRAME

• Ensure before every ride that the lever of the closing mechanism is closed completely
and moved completely into the lever by the lever protection. The frame may otherwise
fold over during the ride! Danger of accident!
• When folding out the frame, ensure that no cable can catch between the two
DANGER
frame parts. Danger of damage and accidents!
WARNING

FOLD IN THE FRAME

1. Turn the lever protection out of the lever
2. Release the lever of the frame quick-clamp
by pulling it towards the rear wheel.
3. Fold in the frame.
FOLDING OUT THE FRAME
1. Fold out the frame. Ensure that you do not catch any ca-
bles.
2. Turn the lever of the frame quick-clamp completely to-
wards the front wheel
protection (fig. Y) latches.
1

SUSPENSION FORK

Many E-bikes are equipped with suspension forks to give you as the rider better cycling com-
fort.
In some models, the spring pre-tension can be adjusted individually. In this case, the fork
may be adjusted to the weight of the rider and payload.
For athletic E-Bikes such as mountain bikes, the type of ground or terrain is also decisive.
The spring pre-tension can be optimally adjusted to the terrain that way.
EN 24
