PART/COMPONENT
1 Shifting grip/lever for gearshift
2 Bell
3 Brake lever
4 Stem
5 Front headlight
6 Rim brake
7 Fork
8 Tyre
9 Valve
10 Disc brake
11 Front motor
12 Foot pedal/pedal arm with pedals
13 Midengine
SCOPE OF DELIVERY
1 x E-Bike (incl. rechargeable battery)
1 x Rechargeable battery charger
All manuals and user guides at all-guides.com
21
22
12
16
COMPONENT DESIGNATION | SCOPE OF DELIVERY
1
26
24
14 Chain gearshift
15 Hub gearshift
16 Bicycle stand
17 Reflector
18 LED tail light with reflector
19 Luggage carrier
20 Ring lock
21 Saddle
22 Seat post
23 Damper/shock
24 Folding frame with closing mechanism
25 Rechargeable battery
26 Control display/operating unit
1 x Operating instructions
1 x Tool set
