LED CONTROL DISPLAY
The drive system is operated with the LED-control dis-
play on the left side of the handlebar.
It shows all information that you need for operating
the E-bikes (fig. AQ):
ON/OFF button
1
Plus button +
2
Speed level
3
Light sensor
4
Rechargeable battery status
5
Minus button -
6
SWITCHING THE DRIVE SYSTEM ON/OFF
• If you switch off the drive system, the lighting is switched off as well. Danger of
accident!
WARNING
1. Keep the button
1
You can also switch on the lighting again when the drive system was switched off first (s.
chapter Lighting). The SAMSUNG luggage carrier and the AEG/BLAUPUNKT down tube re-
chargeable battery switch off on their own after approx. 1 hour of inactivity. Push the button
on the rechargeable battery to reactivate the rechargeable battery.
All manuals and user guides at all-guides.com
This button switches the drive system on and off.
This button increases pedalling support by one level each. Keep the button
pushed for a few seconds to activate the pushing aid.
The LED lamps show which pedalling support level you have currently en-
gaged.
The light sensor regulates the display brightness of the LED lamps of the
control display.
The LED lamps show the current charging status of the rechargeable battery.
This button reduces pedalling support by one level each.
Keep the button pushed for 2 seconds to activate or deactivate the lighting.
(fig. AQ) of the LED-control display pushed for approx. 1.5 seconds.
AQ
2
1
6
DRIVE SYSTEM
3 4
5
