teeth of the upper guide roller of the derailleur and the cassette teeth should be five to seven
millimetres.
SET THE FRONT DERAILLEUR
• If there are any grinding sounds at the front derailleur during the ride, check the set-
tings of the front derailleur at once. Otherwise, there may be damage to the chain and
the gearshift.
Danger of damage!
WARNING
1. The guide plate of the front derailleur must be 2-3 millime-
tres above the teeth of the large blade and run in parallel to
the large chain ring. (Fig. BV) Correct the position of the front
derailleur if necessary.
2. Switch to the smallest chain ring and the largest pinion of
the rear derailleur to set the swivel range of the front derail-
leur.
3. Turn the screw L
1
guide plate without grinding (fig. BW).
4
4. Switch onto the largest chain ring and the smallest sprocket
of the rear derailleur.
5. Adjust the chain with the screw H
outer guide plate
3
REMOVING THE REAR WHEEL
1. V-brake rim brake: Disconnect the brake cable
in order to take out the wheel more easily later.
Hydraulic rim brake: Open the quick-clamping lever
BY) of the rim brake [OPEN].
2. Hydraulic rim brake: Take the brake cylinder
tilever socket (fig. BY) in order to take out the wheel
1
more easily later.
3. Pull the plug of the motor cable (model with rear wheel
motor).
4. Loosen the axle nuts on both sides of the rear wheel with
an 18 mm wrench or release the lever of the quick tensioner
(depending on equipment).
5. Take off the axle nuts and the washers.
6. Pull out the rear wheel from the drop-out.
All manuals and user guides at all-guides.com
out until the chain runs past the inner
, so that it runs past the
2
without grinding (fig. BW).
BV
BW
(fig. BX)
1
BX
(fig.
3
off the can-
2
GEARSHIFT
1 2
4
3
1
2
