25. SYSTEM REGISTERS AND FLAGS
Several registers and flags are reserved for the operating system. These may not be used or may only be
partially utilized by application programs:
Registers:
Flags:
Flag addresses beginning at F 800, which are used for operating system functions are entered with the
addresses S Dxx or T Dxx:
1) The programming device permits the entry of the F address, but after [↵] is pressed, the address is
automatically converted to S Dxx or T Dxx format.
Enter:
After [↵] is modified to:
Enter:
After [↵] is modified to:
R 0800 to R 1499
F 800 to F 999
Addresses
F 800
F 801
:
F 899
F 900
F 901
:
F 999
F 820
S D20
F 980
T D80
1)
Entered as
S D00
S D01
:
S D99
T D00
T D01
:
T D99
