Error Messages
The error messages in the table (see previous page) which are marked with ●, are possible for the
respective function on the same line. If an error occurs during the execution of a routine, the Carry Flag
is set and the error number is put into register R 1024.
Error number Description
1 Range overflow during computation
2 Range underflow during computation
3 Division by 0
4 Range overflow during number format conversion
5 Trimming of Lower Significant Byte (LSB) while loading 4 Byte Mantissa
6 Range overflow while loading numbers
7 Range underflow while loading numbers
8 Negative operand for square root computation
9 Invalid character for string conversion routine
10 Not used
11 Invalid command (trap error set off)
12 Number out of range
13 Exponent error in metric-inch or inch-metric conversion
14 Data overflow in metric-inch or inch-metric conversion
