B&R BRCOMP1-0 Anwenderhandbuch Seite 148

B&R COMPACT PLC
10.2 INPUT CIRCUIT
E 0-B
E C-F
GND
Counter and interrupt logic is described in section "14. Counter Inputs and Interrupt Input".
10.3 DIGITAL INPUT WIRING
- 148 -
18 V ... 4 msec.
24 V ... 2 msec.
30 V ... 1.6 msec.
LED
LED
24 VDC
Filter
Filter
20 kHz
Counter and
interrupt
Filter
logic
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
GND
GND
Address,
data
and
control bus
Latch
