13. ANALOG OUTPUTS
Analog outputs are utilized for converting internal numerical values from the PLC into current and
voltage.
13.1 TECHNICAL DATA
Amount
Revision
Addressing
Voltage output
Current output
Resolution D/A conversion
Offset at 25 °C
Offset drift
Gain error at 25 °C
Gain drift
Gain error load
Linearity
Response time constant
Maximum output level at reset
(or before initialization)
1)
LSB ... Least Significant Bit
2
Short circuit protected
Through the operating system
±10 V / 10 mA
0 - 20 mA, load 50 Ω (400 Ω max.)
12 bit
Software compensation to ±1 LSB
±0.02 % of full scale / °C (±0.8 LSB/°C)
Software compensation to ±0.5 %
±0.02 %/°C
0.01 %/Ω
±1 LSB
1)
< 1 msec
±50 mV or -0.3 mA
