9. LEDs
32 LEDs inform the user of digital input status, digital output status, power supply and the CPU
activity.
LEDs for Description
Digital inputs The green LEDs (0 - F) on the left-hand side of the unit indicate the status of the digital
inputs.
Digital outputs The orange LEDs (0 - D) indicate the status of the digital outputs.
Supply The orange LED DCOK indicates, whether power is being supplied or not.
0 0
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
A A
B B
C C
D D
E DCOK
F STATUS
Off ... Input = "0"
On ... Input = "1"
Off ... Output = "0"
On ... Output = "1"
Off ... No supply
On ... Supply voltage OK.
