Inputs/Outputs Description
FILTER Defines the filter for both channels.
Filter
Defines the conversion time of channel 1 (0 - 255).
RATE
255
ALARM indicates a signal failure or an exceed on a channel.
7
INPUT0 Contains the converted value of channel 0.
Value range:
Frequency Conversion time
0 10 Hz 302 msec.
1 50 Hz
2 250 Hz 16.2 msec.
3 1000 Hz
0 ... Channel 1 is never converted
1 ... Channel 1 is always converted to channel 0
2 ... Channel 1 is converted to double channel 0
: ... :
: ... :
... Channel 1 is converted to 255 times channel 0
O1 D1 O0 D0
0
Signal
±10 V
±2.5 V
0 - 20 mA
-50.00 to +150.00 °C
-58.00 to +302.00 F
0 - 65000 Ω
0 - 4500 Ω
Resolution
±14 bit
62 msec. ±14 bit
±12 bit
4.1 msec. ±8 bit
Channel 1 exceeded
Signal failure channel 1
Channel 0 exceeded
Signal failure channel 0
Value
-32768 to +32767
-32768 to +32767
0 to 32767
-5000 to +15000
-5800 to +30200
0 to 65000
0 to 4500
B&R COMPACT PLC
Address types
R, #
R, #
R
R
