Installation

Mechanical Installation

Unpacking the Inverter
Check the following items after unpacking the inverter.
Has the correct Inverter model been
delivered?
Is the Inverter damaged in any way?
Are any screws or other components
loose?
Additionally check that following parts are delivered in the package with the IP54 inverter.
If any irregularities in the above items are found, contact the agency from which the Inverter was pur-
chased or your Omron Yaskawa Motion Control representative immediately.

Checking the Installation Site

Observe the following precautions when mounting the Inverter.
•
Install the Inverter in a clean location which is free from oil mist and dust.
•
When installing or operating the Inverter, always take special care so that metal powder, oil,
water, or other foreign matter does enter the Inverter.
•
Do not install the Inverter on combustible material, such as wood.
•
Install the Inverter in a location free from radioactive materials and combustible materials.
•
Install the Inverter in a location free from harmful gasses and liquids.
•
Install the Inverter in a location without excessive oscillation.
•
Install the Inverter in a location free from chlorides.
•
Install the Inverter in a location without in direct sunlight.
•
The IP54 Inverters provide protection from non-conductive dust and splashing water from all
directions. Install the Inverter indoors in a heated and controlled environment to avoid condensa-
tion inside the Inverter. Keep any water or dust outside of the IP54 Inverter when wiring.
•
Ensure that the door locks are closed before carrying the Inverter. Always hold the case when
carrying the Inverter, do not carry it holding the door or the cable glands. If the door locks are
open or the Inverter is held by the door (or cable glands) when carrying the main body of the
Inverter may fall, possibly resulting in injury.
•
Pay attention not to damage the cable glands when lifting. Otherwise the equipment may be dam-
aged by ingress of water or dust. Mount the blind plugs attached for option and control entry if
these terminals are not connected
•
Pay attention not to damage the cable glands during the installation
EN-5
Item
Check the model number on the nameplate on the side of the
Inverter.
Inspect the entire exterior of the Inverter to see if there are any
scratches or other damage resulting from shipping.
Use a screwdriver or other tools to check for tightness.
Part Name
Cable Gland (for Input)
Cable Gland (for Motor Output)
Cable Gland (for Control)
Cable Gland (for Fieldbus)
Door Key
Blind Plug (Control Cable Entry)
Blind Plug (Fieldbus Cable Entry)
Method
Qty.
1
1
1
1
1
1
1
