Setting
Description
Digital Input Function Selections (H1-01 to H1-05)
3
Multi-step speed reference 1
4
Multi-step speed reference 2
Jog frequency command (higher priority than multi-
6
step speed reference)
F
Not used (Set when a terminal is not used)
14
Fault reset (Reset when turned ON)
19
PI control disable
External fault; Input mode: NO contact/NC contact,
20 to
2F
Detection mode: Normal/during operation
Digital Output Function Selections
(H2-01 and H2-02)
During run 1 (ON: run command is ON or voltage is
0
being output)
Inverter operation ready; READY: After initialization or
6
no faults
F
Not used. (Set when the terminal is not used.)
EN-22
