5. Insert the lamp socket into the housing and lock the pane
in place.
A
Fig. 42 Replacing the front direction indicator lamp
Rear lights
To change the rear direction indicators and the rear light,
proceed as follows:
1. Loosen the two screws with a small flathead screwdriver
and remove the protective pane.
2. Remove the defective bulb from the holder and replace it
with a new one.
3. Reattach the protective pane with the two screws.
C2000
B C
01 / 2010
Fig. 43 Disassembling the rear lights
1 Direction indicator bulb 2 Rear light bulb
Malfunctions / Troubleshooting
1
2
Page 181
