Erweiterte Funktionalität
The number of error message and mes‐
sage text
(#43) Es ist nicht möglich, den Testfunk‐
tion-Mode zu setzen. (IDryRunMo‐
de::SetDryRunMode)
Messages about problems at setting breakpoints and setting variables for watching
(#12) Die Anzahl der Breakpoints ist be‐
grenzt. Es ist nicht möglich, einen Break‐
points zu aktivieren oder einen neuen zu
setzen.
(#2) Es ist nicht möglich, die gewünschten
Operationen im Breakpoint-Dialog auszu‐
führen.
(#14) Es ist nicht möglich, einen Break‐
point zu erstellen oder zu aktivieren.
(#89) Es ist nicht möglich einen Break‐
point zu aktivieren oder einen aktiven
Breakpoints zu setzen, weil der aktuelle
NC-Mode nicht der NC-Analyzer-Mode
ist.
(#92) Es ist nicht möglich, einen aktiven
Breakpoint zu setzen, weil der Test-
Modus nicht gesetzt ist.
(#13) Die Anzahl der zu beobachtenden
Variablen und Breakpoints auf Variablen
ist begrenzt. Es ist derzeit nicht möglich,
eine weitere Variablen zum asynchronen
Überwachen auszuwählen oder einen
Breakpoint auf eine Variable zu setzen.
(#121) Der Breakpoint auf die Variable
<Variablen-Name>, is erreicht. Der Zu‐
griffsmode ist: Schreiben!
(#122) Der Breakpoint auf die Variable
<Variablen-Name>, is erreicht. Der Zu‐
griffsmode ist: Lesen!
Messages about problems of loading information from the configuration file
Rexroth IndraMotion MTX 09VRS | Anwendungsbeschreibung
and Controls
The probable reason
An attempt to cancel the regime
DryRunMode by the button General
Inhibit ON (F6) in case of working
with NC-emulator.
The number of active breakpoints
has been exceeded.
An attempt to activate, with the help
of the dialogue «Breakpoints», one
or some breakpoints of inactive flow
program.
An attempt to change the access
mode of one or some breakpoints,
juxtaposed to variables, of inactive
flow program.
An attempt to set the active break‐
point in the inactive flow program.
An attempt either to activate a
breakpoint or to set an active break‐
point, when NC-Analyzer Mode
was not set.
An attempt to set the active break‐
point in the inactive flow program.
NC-Analyzer Mode was not set, at
that.
An attempt to set an active break‐
point with the help of the mouse
when the regime DryRunMode was
not set.
The number of either asynchro‐
nously watched variables or break‐
points, juxtaposed to variables, has
been exceeded.
Messages about reaching breakpoints, juxtaposed to variables
The interrupt of flow program exe‐
cution at the breakpoint, juxtaposed
to the variable.
The interrupt of flow program exe‐
cution at the breakpoint, juxtaposed
to the variable.
Recommendations to a user
Continue the work, because in case of wor‐
king with NC-emulator the regime DryRunMo‐
de is always set, and clicking the button
General Inhibit ON (F6) doesn't cancel this
regime.
Delete or deactivate either one or some active
breakpoints.
Proceed the work or select the flow program
with given breakpoint(s) as active one, then
make desired actions with breakpoint(s).
Proceed the work or select the flow program
with given breakpoint(s) as active one, then
make desired actions with breakpoint(s).
The breakpoint in this case will be inactive
(also in case, when the flow program beco‐
mes active).
Set NC-Analyzer Mode. Then make desired
actions with breakpoints.
Select desired flow program as an active one.
Set NC-Analyzer Mode. Then make desired
actions with breakpoint(s).
Set DryRunMode (NC-Analyzer Mode also
should be set), then set a breakpoint.
Delete from the list of asynchronous watching
as many variables, as it is necessary to add.
Delete or deactivate as many breakpoints,
juxtaposed to variables, as it is necessary to
add.
Proceed the work.
Proceed the work.
