Graphs
15
Graphs
15.1
Diagram Shape of Current (2-stroke / 4-stroke)
2-stroke
main current
secondary current
ignition current
min. current
torch button
start/stop
torch button
secondary current
4-stroke
main current
secondary current
start current
end current
ignition current
torch button
start/stop
torch button
secondary current
01.22
pressed
pressed
pressed
909.1719.9-07
pressed
pressed
- 39 -
