Before commissioning
11 Before commissioning
11.1 Fasten transportation belt
6
Transportation belt
15
Plastic slides
16
Velcro fastener
11.2 Fastening accessories belt
13
Accessories belt with fastener
15
Plastic slidesr
17
Belt fastener
01.22
15
909.1719.9-07
15 6
 Thread the transportation belt into the welding machine
and plastic slides. See sequence of the numbering in the
picture.
13
 Thread the accessories belt into the handle and plastic
slides. See sequence of the numbering in the picture.
 Plug the belt fasteners together.
16
17
