LORCH HandyTIG 200 AC/DC ControlPro Bedienungshandbuch Seite 37

Technical data
Code Error
Temperature sensor secondary
E13-01
diode
Temperature sensor primary
E13-02
module
E13-03 Temperature sensor transformer
E13-04 Temperature sensor PFC
E14-00 Supply voltage
E15-00 Current detection
E16-00 Overcurrent protective switch off
E19-00 Ignition device
E22-00 Low voltage mains
E25-00 Voltage Reduction Device (VRD)
E30-00 Error configuration
E30-03 User panel identification
E33-01 Power unit
E34-00 Fan
Tab. 10: Error messages
14 Technical data
Technical data
1)
TIG welding
Welding range min - max
Idle voltage (peak value in accordance
with EN 60974-1)
Current setting
Slope characteristic
Welding current at ED 100%
Welding current at ED 60%
ED at maximum welding current
Current consumption I1 (at ED 100%)
Current consumption I1 (at ED 60%)
Current input I1 max
Maximum effective mains current
(I1eff )
Power consumption S1 (at ED 100%)
Power consumption S1 (at ED 60%)
Input power S1 max
01.22
Cause
Thermal sensor defective
Fault internal supply voltage
Error at the current detection
Current consumption of power unit too
high
Ignition unit faulty
Mains voltage too low
Voltage Reduction Device defective or
short circuit between workpiece and torch
Wrong or broken pc-board, wrong system-
software was flashed
User panel identification error
Power unit not symmetrical
Fan current to high
HandyTIG 200
AC/DC
A 3 - 200
V 10,1 - 18,0
V/DC < 111
Infinitely vari-
able
falling
A 160
A 180
% 45
A 15,0
A 17,4
A 19,9
A 15,0
kVA 3,5
kVA 4,0
kVA 4,6
909.1719.9-07
Inform Service
Inform Service
Inform Service
Inform Service
Inform Service
Check mains voltage
Torches and electrode holders must not have
electrical contact to the ground cable (short
circuit) when switched on
Inform Service
Inform Service
Inform Service
Inform Service
Technical data
1)
Electrode welding
Welding range min - max
Idle voltage (peak value in accordance
with EN 60974-1)
Current setting
Slope characteristic
Welding current at ED 100%
Welding current at ED 60%
ED at maximum welding current
Current consumption I1 (at ED 100%)
Current consumption I1 (at ED 60%)
Current input I1 max
Maximum effective mains current (I
Power consumption S1 (at ED 100%)
Power consumption S1 (at ED 60%)
Input power S1 max
Weldable electrodes
Possible remedy
HandyTIG 200
AC/DC
A 10 - 170
V 20,4 - 26,8
V/DC < 111
Infinitely
able
falling
A 120
A 140
% 40
A 15,9
A 19,3
A 24,1
) A 15,9
1eff
kVA 3,7
kVA 4,4
kVA 5,5
mm 1,5 - 4,0
- 37 -
